AB SERIES - 1-3/8" DUAL SPLINED SHAFTAB100DP
Specifications
GPM 26.4
PSI 870
RPM 550
Bore 1.571 in./40 mm
Stroke 1.78 in./45 mm
HP 15.7 EBHP
Ship Weight 90.4 lbs.
DetailsAB SERIES – 1-3/8″ DUAL SPLINED SHAFT
-
AB SERIES - SOLID SHAFT (LEFT) AND 1-3/8" SPLINED SHAFT (RIGHT) Also available with solid shaft (right) and PTO (left), add “L” to end of part number (ex. AB100PSL)AB100PS
Specifications
GPM 26.4
PSI 870
RPM 550
Bore 1.571 in./40 mm
Stroke 1.78 in./45 mm
HP 15.7 EBHP
Ship Weight 90.4 lbs.
DetailsAB SERIES – SOLID SHAFT (LEFT) AND 1-3/8″ SPLINED SHAFT (RIGHT)
Also available with solid shaft (right) and PTO (left), add “L” to end of part number (ex. AB100PSL) -
AB SERIES - 1-3/8" DUAL SPLINED SHAFT
AB120DP
Specifications
GPM 31.7
PSI 870
RPM 550
Bore 1.78 in./45 mm
Stroke 1.78 in./45 mm
HP 18.7 EBHP
Ship Weight 90.4 lbs.
DetailsAB SERIES – 1-3/8″ DUAL SPLINED SHAFT
-
AB SERIES - SOLID SHAFT (LEFT) AND 1-3/8" SPLINED SHAFT (RIGHT) Also available with solid shaft (right) and PTO (left), add “L” to end of part number (ex. AB100PSL)
AB120PS
Specifications
GPM 31.7
PSI 870
RPM 550
Bore 1.78 in./45 mm
Stroke 1.78 in./45 mm
HP 18.7 EBHP
Ship Weight 90.4 lbs.
DetailsAB SERIES – SOLID SHAFT (LEFT) AND 1-3/8″ SPLINED SHAFT (RIGHT)
Also available with solid shaft (right) and PTO (left), add “L” to end of part number (ex. AB100PSL) -
AB SERIES - 1-3/8" DUAL SPLINED SHAFT
AB180DP
Specifications
GPM 47.6
PSI 870
RPM 650
Bore 1.97 in/50 mm
Stroke 1.78 in./45 mm
HP 28.4 EBHP
Ship Weight 90.4 lbs.
DetailsAB SERIES – 1-3/8″ DUAL SPLINED SHAFT
-
AB SERIES - SOLID SHAFT (LEFT) AND 1-3/8" SPLINED SHAFT (RIGHT) Also available with solid shaft (right) and PTO (left), add “L” to end of part number (ex. AB100PSL)AB180PS
Specifications
GPM 47.6
PSI 870
RPM 650
Bore 1.97 in/50 mm
Stroke 1.78 in./45 mm
HP 28.4 EBHP
Ship Weight 90.4 lbs.
DetailsAB SERIES – SOLID SHAFT (LEFT) AND 1-3/8″ SPLINED SHAFT (RIGHT)
Also available with solid shaft (right) and PTO (left), add “L” to end of part number (ex. AB100PSL) -
AB SERIES - 1-3/8" DUAL SPLINED SHAFT
AB90DP
Specifications
GPM 23.8
PSI 870
RPM 650
Bore 1.42 in./36 mm
Stroke 1.78 in./45 mm
HP 14.2 EBHP
Ship Weight 90.4 lbs.
DetailsAB SERIES – 1-3/8″ DUAL SPLINED SHAFT
-
AB SERIES - SOLID SHAFT (LEFT) AND 1-3/8" SPLINED SHAFT (RIGHT) Also available with solid shaft (right) and PTO (left), add “L” to end of part number (ex. AB100PSL)
AB90PS
Specifications
GPM 23.8
PSI 870
RPM 650
Bore 1.42 in./36 mm
Stroke 1.78 in./45 mm
HP 14.2 EBHP
Ship Weight 90.4 lbs.
DetailsAB SERIES – SOLID SHAFT (LEFT) AND 1-3/8″ SPLINED SHAFT (RIGHT)
Also available with solid shaft (right) and PTO (left), add “L” to end of part number (ex. AB100PSL) -
AT SERIES AT0033 - 1-3/8" SPLINED SHAFTAT0033
Specifications
GPM 7.93
PSI 435
RPM 650
Bore 1.417 in./36 mm
Stroke 0.945 in./24 mm
HP 2.4 EBHP
Ship Weight 28.0 lbs.
DetailsAT SERIES AT0033 – 1-3/8″ SPLINED SHAFT
-
AT SERIES AT0055 - SINGLE PTO SHAFT, RIGHT SIDEAT0055
Specifications
GPM 13.22
PSI 725
RPM 650
Bore 1.417 in./36 mm
Stroke 0.945 in./24 mm
HP 6.6 EBHP
Ship Weight 36.0 lbs.
DetailsAT SERIES AT0055 – SINGLE PTO SHAFT, RIGHT SIDE
-
AT SERIES AT0055 - 1-3/8" SPLINED AND 35 MM SOLID SHAFT - SPLINED SHAFT ON RIGHT, SOLID SHAFT ON LEFT
AT0055DS
Specifications
GPM 13.22
PSI 725
RPM 650
Bore 1.417 in./36 mm
Stroke 0.945 in./24 mm
HP 6.6 EBHP
Ship Weight 36.0 lbs.
DetailsAT SERIES AT0055 – 1-3/8″ SPLINED AND 35 MM SOLID SHAFT – SPLINED SHAFT ON RIGHT, SOLID SHAFT ON LEFT
-
AT SERIES AT0055 - 1-3/8" SPLINED AND 35 MM SOLID SHAFT - SOLID SHAFT ON RIGHT, SPLINED PTO ON LEFT
AT0055DSL
Specifications
GPM 13.22
PSI 725
RPM 650
Bore 1.417 in./36 mm
Stroke 0.945 in./24 mm
HP 6.6 EBHP
Ship Weight 36.0 lbs.
DetailsAT SERIES AT0055 – 1-3/8″ SPLINED AND 35 MM SOLID SHAFT – SOLID SHAFT ON RIGHT, SPLINED PTO ON LEFT
