MF

• Flows 71.0 GPM to 106.0 GPM
• Packings/plungers serviceable without removing manifold
• Splash lubrication
• Gear ratios: 1500 RPM=1.876:1, 1800 RPM=2.238:1, 2200 RPM=2.722:1, 2600 RPM=3.25:1
• Nickel-plated cast iron manifold
• F2152 kit allows for easy adaptation to MSS mounting pattern

MF Series – Specifications:
Max. Inlet Pressure: 45 PSI
Max. Fluid Temperature:    *140° F
Inlet Port Thread: See specification sheet
Discharge Port Thread: See specification sheet
Shaft Diameter:   1.969″/50 mm
Stroke: 2.756″/70 mm
Pump Dimensions: 29.5″x23.0″x14.5″
Crankcase Oil Capacity: 304.3 oz./9 liters
Use GP Series 220 Oil

* Please consult technical manual or GP Sales Representative for Temperature/Inlet Pressure information
