• Flows from 4.1 GPM to 5.5 GPM
  • Patent-pending symmetrical power end featuring top and bottom mounting holes allowing for easy left to right shaft conversion
  • Low-high pressure packing design with integrated cooling system
  • Horizontally fitted in-line valves
  • Splash lubrication
  • SAE-C hydraulic drive options available
  • 420 SS manifold

KV Series – Specifications:
Inlet Pressure: 75-100 PSI
Max. Fluid Temperature: *86° F
Inlet Port Thread: 3/4″ BSP-F
Discharge Port Thread: 1/2″ G Special
Shaft Diameter: 1.181″/30 mm
Stroke: 0.905″/23 mm
Pump Dimensions: 18.2″ x 14.3″ x 7.2″
Crankcase Oil Capacity: 128.5 oz./3.8 liters
Use GP Series 220 Oil

* Please consult technical manual or GP Sales Representative for Temperature/Inlet Pressure information

Showing all 2 results

  • KV12

    Specifications

    GPM

    PSI

    RPM

    1750

    Ship Weight

    88 lbs.

    View Details

    KV Sell Sheet

    Download

    KV Owner's Manual

    Download

    KV Repair Manual

    Download
    KV SERIES
  • KV14

    Specifications

    GPM

    PSI

    RPM

    1750

    Ship Weight

    88 lbs.

    View Details

    KV Sell Sheet

    Download

    KV Owner's Manual

    Download

    KV Repair Manual

    Download
    KV SERIES
